Ahmed LRI Angle, Specialty Model Step Diamond Knife

SKU: 11.319.6091
Legacy SKU#: SSSL AH
Tags: Angulated Step Scalpel, Astigmatic Keratotomy, Diamond Blade, Diamond Knife, Iqbal Ike K. Ahmed, Limbal Relaxing Incisions, Limbal Relaxing Incisions, LRI Step Shortie, MD, Paracentesis, Slit Lamp AK/LRI, Step Diamond Knife
Login or Sign up to view prices.
Login or Sign up to view prices.


The Ahmed LRI Angle Specialty Model is designed for limbal relaxing incisions (LRI), astigmatic keratotomy (AK), paracentesis.

Features

  • Specially designed footplate with a 35° angled handle allows pen‑style grip for improved comfort and enhanced blade visualization.
  • Shorter handle profile enables easy slit‑lamp use for post‑cataract astigmatism enhancement, while remaining effective in the supine OR setting.
  • Ultra-thin blade design (100-120 μm) combined with a neutral, non-self-directing faceting bias, with three edges and one sharp enhancement edge.
  • Preset thimble depth options from 0.50 to 0.75 mm provide consistent, controlled cutting.
  • Fully rehonable construction ensures lasting cutting performance and long‑term reliability for high‑volume ophthalmic practices.

Our Commitment to Quality Mastel Surgical maintains strict standards upon width and length, requiring diamond replacement at times to maintain performance standards. Mastel Surgical handles are manufactured from Titanium, delivering a lightweight, highly durable instrument with exceptional precision and control.



Summary Table
Weight 1 lbs
Dimensions 4.32 × 3.37 × 0.262 in
Tip Angle 35°
Tip Width 0.2 mm
Blade Width 1 mm
Useful Length 3.5 mm (at full extension)
Thimble Ahmed Angulated Slit Lamp
Depth Settings 0.00, 0.50, 0.55, EXT, RET, 0.60, 0.65, 0.70, 0.75
Blade Thickness 100-120 μm (UltraThin)
Blade Faceting Neutral (not self-directing)
Blade Rehonability Rehonable
Other Features 3 Edges, 1 Sharp Enhancement Edge

Extended Description

While many surgeons would feel uncomfortable performing astigmatic keratotomies at the slit lamp as a post op corneal adjustment with these relaxing incisions, Doctor Ike Ahmed makes a strong point as to how well it can be done in a facile and convenient manner for doctor and patient.

Testimonials

Steven G Safran, MD: “I’ve been doing slit lamp LRI’s for many years and find that they are safe, well tolerated, reliable, fast and really powerful for touching up outcomes in post operative situations ranging from months to years after cataract surgery. The Mastel Ahmed LRI Angle PHD II (short handle) offers exquisite control of all aspects of this procedure leading to better outcomes and better confidence when I offer this option than what I was used to previously using other diamonds. I already owned over a dozen short handled diamond blades for doing slit lamp LRI’s but after trying the Mastel blade I bought 2 of them and use them exclusively in my office because it was clear I could achieve better outcomes with those and that makes a real difference that patients and my staff are able to notice. Well worth the investment!”

Iqbal "Ike" K. Ahmed, MD: “Slit lamp AKs are a great way to touch-up small degrees of postoperative astigmatism. Firstly, we carefully designed a one-step marker with preset treatment zone and arcuate lengths to provide surgical guidance. The angled PhD blade is optimized for safe and efficient slit lamp arcuate incisions allowing the surgeon to twirl the handle while cutting in either direction with the protection of depth guard to prevents epithelial dragging. A diamond is ideal for smooth and controlled cuts. We have been very pleased with our results in our post-IOL patients, where small degrees of cylinder can degrade visual quality and acuity.”

Contributors

Designed By Iqbal ‘Ike’ K. Ahmed, MD, University of Toronto "Ike_Ahmed-e1614383573659-200x176.png"

Note about Diamond Knives: Mastel maintains strict standards upon width and length, requiring diamond replacement at times to maintain performance standards.

Please contact Mastel in regards to diamond availability and lead times. Call 1-800-657-8057, or email: sales@mastel.com.
